ML-40PT : 동도테크 | 정밀 측정 토털솔루션

Model	ML-40PT-S	ML-40PT-A
Display	7" Color LCD
Resolution	0.001mm or 0.01mm (Option : 0.0001mm)	0.0001mm
Input channels	1Ch ~ 32Ch	Air 1Ch ~ 12Ch
Size(mm) W x H x D	360 x 135 x 285
Power input	AC100~220V 50Hz/60Hz
Calculation modes	Maximum, Minimum, Max-min, Average, Sum, Plus, Minus, etc..
Data communication	RS232C (Option :RS485)
Serial command	-
I/O Port	15PIN : 6 Inputs(START, ZERO, MODEL BIT, etc) / 6 Outputs(OK, NG, READY, etc) Option : 25PIN-Extended I/O (Add more outpins)
Data storage	-
Compatibility	DP series(DONG-DO analog probes) (Option: other makers)	Air

종류

ML-40PT-S Series (스탠다드 모델, Probe 전용)

ML-40PT-A Series (AIR GAUGE 전용)
