ML-CP : 동도테크, 아날로그 변위센서(1~25mm), 디지털 변위센서(15mm)

알림

동도테크 제품(프로브센서, 측정기, 악세서리)

3.5인치 컬러 TFT LCD
터치패널로 사용자 편의성 증대
다양한 측정모드 및 히스토그램
( ＋ , - , AVG , MAX-min )
RS232C / RS485
I/O 인터페이스

Model	ML-CP-S	ML-CP-R	ML-CPD	ML-CP2-S	ML-CP-A	ML-CP-F
Display	3.5" TFT color LCD with touch panel
Resolution	0.001mm or 0.01mm (Option: 0.0001mm)				0.0001mm	Dependent on Load cell
Input channels	1Ch ~ 4Ch				Air 1Ch ~ 2Ch	Load cell 1Ch
Size W x H x D	99.5 × 99.5 × 153.5 (mm)
Panel hole W x H	93 × 93 (mm)
Power input	AC100~220V 50Hz/60Hz		DC 24V	AC100~220V 50Hz/60Hz
Calculation modes	Peak, Off-peak, Maximum, Minimum, Max-min, Average, Sum, Diameter(3point), Plus, Minus, Absolute value, etc.
Data communication	RS232C (Option: RS485)
Serial command	CLEAR , ZERO , RESET , START , RECALL
I/O Port	15PIN : 6Inputs(START,ZERO,MODEL BIT, etc) / 6 Outputs(OK, NG, READY, etc)
Data storage	-
Compatibility	DP series(DONG-DO analog probes) (Option: other makers)			Digital(DL)	Air	Load cell

종류

ML-CP S Series (PROBE 전용)

ML-CP R Series (RUNOUT 전용)

ML-CPD Series (전원 24V 사용)

ML-CP A Series (AIR GAUGE 전용)

ML-CP F Series (압입력_LOADCELL 전용)

AMP-100 ML-CPD (Input DC 24V)

S
